• Barksdale Series 9675 Sealed Piston Pressure Switch, Housed, Single Setpoint, 425 to 6000 PSI, A9675-4-AA

Barksdale Series 9675 Sealed Piston Pressure Switch, Housed, Single Setpoint, 425 to 6000 PSI, A9675-4-AA

$385.00 $346.50346.5USD
Are you buying in volume? Are you an OEM? Are you a reseller? Be sure to contact FLW directly for your special pricing.
Quantity:
Availability:
PART NUMBER:
A9675-4-AA
Shipping Weight:
2.00 LBS
Shipping:
Calculated at checkout

Description

Barksdale's Series 9675 & A9675 Sealed Piston Pressure Switches offer extremely long life in a robust package, making them the ideal solution to your industrial pressure control needs. Sealed Piston switches are ideal for applications demanding rapid cycling at high pressure. Available in various pressure ranges up to 6000 psi, sealed piston switches are suitable for use in industrial applications such as hydraulic presses, compactors, and machine tools. All models feature a durable, anodized aluminum enclosure with a tamper proof adjustment screw cover and an integrated 1/2" NPT conduit connector, and are rated to NEMA 13 as a standard. For applications requiring a highly accurate switch in a durable package, Barksdale's Series 9675 & A9675 Sealed Piston Pressure Switches are the ideal choice.

Features:
  • Double make double break capability
  • Extremely long life
  • Calibrated dial for easy setpoint adjustment
  • Tamper-proof external adjustment
  • Oil & dust tight
  • Easy setpoint adjustment

Applications:
  • Hydraulic applications
  • Machine tools
  • Compressors
  • Mining
  • Specialty vehicles
  • Lubrication equipment
  • Metal working


Factory preset setpoint options are available. Contact FLW for further information.

Product Specifications

General Specifications

Accuracy:± 2% of the adjustable range
Electrical Connectors:Through 1/2" NPT conduit connection to screw terminals
Pressure Connection:1/4" NPT female
Adjustable Range
Decreasing - psi (bar)Increasing - psi (bar)
minmaxminmax
425 (28.9)5500 (374)600 (40.8)6000 (408)
Switch
Type:Double make double break (DMDB) snap action; single circuit
Rating:15 amps @ 125/250/480 VAC; 7.5 amps @ 600 VAC; 0.5 amps @ 250 VDC
Wetted Parts
O-ring:Buna-N with Teflon® backup ring
Process Fitting:416 stainless steel
Piston:416 stainless steel
Deadband:Adjustable deadband
Enclosure:Anodized aluminum
